Buick Encore: Exterior Lamp Controls
.gif)
The exterior lamp control is on the instrument panel to the left of the steering column.
There are four positions:
.gif)
: Turns the exterior lamps off
and
deactivates the AUTO mode. Turn
O again to reactivate the
AUTO mode.
In Canada, the headlamps will automatically reactivate when the vehicle is shifted out of P (Park).
AUTO : Turns the exterior lamps on and off automatically depending on outside lighting.
.gif)
: Turns on the parking lamps
including all lamps, except the
headlamps.
.gif)
: Turns on the headlamps
together with the parking lamps and
instrument panel lights. A warning
chime sounds if the driver door is
opened when the ignition is off and
the headlamps are on.
Headlamp High/ Low-Beam Changer
.gif)
.gif)
: Push the turn signal
lever away
from you and release, to turn the
high beams on.
To return to low beams, push the lever again or pull it toward you and release.
.gif)
This indicator light turns on in
the
instrument cluster when the
high-beam headlamps are on.
Flash-to-Pass
To flash the high beams, pull the turn signal lever all the way toward you. Then release it.
Daytime Running Lamps (DRL)
Daytime Running Lamps can make it easier for others to see the front of your vehicle during the day. Fully functional DRL are required on all vehicles first sold in Canada.
A light sensor on top of the instrument panel makes the DRL work, so be sure it is not covered.
The DRL system makes the low-beam headlamps come on at a reduced brightness when the following conditions are met:
- The ignition is on.
- The exterior lamp control is in AUTO.
- The engine is running.
When the DRL are on, the taillamps, sidemarker, instrument panel, and other lamps will not be on.
The headlamps automatically change from DRL to the regular headlamps depending on the darkness of the surroundings. The other lamps that come on with the headlamps will also come on.
When it is bright enough outside, the headlamps go off and the DRL come on.
The DRL turn off when the
headlamps are turned to .gif)
or the
ignition is off. For vehicles first sold
in Canada, this control only works
when the vehicle is parked.
